5U GPU Server Case
| Model: | 5U GPU Barebone System |
| 5U 8GPU customized chassis: | 483mm(W)*880mm(D)*220mm(H) |
| Material: | 1.0mm SGCC Zinc-Coated Steel |
| Drive bays: | 4 x 3.5′ hot-swappable SATA (II or III) / SAS (II or III) 12Gb/s drive bays |
| Cooling fan: | 6*12 cm fan （12038 chassis fans*3/ GPU reinforcement fans*3） |
| Dual-port cards | 4 pieces of 8654-8i dual-port cards(optional) |
| GPU riser card： | 8 pieces of GPU riser card(Gen4),8 * PCIE3.0X16, supports up to 8 public GPUs. |
| M/B form factor: | Support motherboard size up to E-ATX (12"*13") |
| Power board: | Supports standard CRPS power modules, adopts 4+1 redundancy mode, and comes standard with 4*1600W power modules. |
| Power : | 1600W CRPS*4 |
| Connector | 2*USB3.0 |
| System Control | 1*Power SW ，1*Reset SW，1*LAN LED，1*Alert LED. |
| Cable: | 8 pieces of 8654-8i dual-header cables |
| Motherboard cable: | Motherboard 24pin power supply cable*1 |
| CPU power supply cable: | CPU power supply cable*2 |
| GPU backplane power supply cable: | GPU backplane power supply cable*4 |
| 4090 VGA card power cable: |  4090 VGA card power cable*8 |
| Hard disk backplane power cable: | hard disk backplane power cable*1 |
